Thank you for confirming that I'm not the only one experiencing this, and narrowing it down to the Security Update. I was beginning to pull my hair out. Unfortunately I've already deployed that update to the majority of our Macs.

I have the same exact issue on 3 of my mac at home (Macbook Pro 15" Retina mid-2015, another 2012, and macmini 2011).
All pausing randomly due to windowserver hanging. Has apple provided any updates in your case? I find that odd that not more people are seeing this issue. Is there an apple forum thread for this issue? The only one I could find is different and talks about a complete freeze. Where as in this case it's a hang which last about 3-4 seconds and comes back and forth until reboot. The problem starts for me after 3-4 days of use sometime sooner.

@onyx4 See the two "Apple Discussion" links in my post. Your experience is the same as mine... and @AVmcclint we've also deployed it everywhere. Not quite ready to roll out Sierra (waiting on an Endnote X8 upgrade purchase, which is in .gov purchasing hell), so we are stuck...

This is good to know. I was seeing this on one machine, and was thinking it was something on my end!

Just had a crash that fits this profile on a machine running 10.12.2- the behavior was exactly the same as what you describe, and the window server spin dump from the crash time is basically the same.
Has anyone seen this on 10.12.1?

Maybe this is related to a conflict with a particular software ? Especially the video driver could be at fault where some security fixes were made. I have VMware fusion and Duet display installed on the Macs where I see the issue.

Is anyone else running McAfee EPM or ENS? We saw this same behavior until we rolled out ENS 10.2.1 and hotfix 1159589, and it has since gone away.

Disabled SEP (A/V) and any other third-party software save for Casper Suite. Problem still occurred. Since we're seeing this on all our Mac hardware, and I'm seeing reports from "consumers" on Apple Discussions, I suspect that this is problem is widespread, at least on 10.11.6. Can't speak to Sierra as we're still testing it and it's not widely deployed.

I've had this problem on a 2013 Mac Pro since around the 2nd week in December 2016

Each time the graphics hangs, I see this line in the kernel log:

stalling for detach from AMDTahitiGraphicsAccelerator

The machine is otherwise (i.e via SSH) responsive. The problem seems exacerbated with large windows. Chrome or Safari full screen causes hanging, where as resized into a smaller window seems better. The problem can take a day or two to appear after a reboot.

My Mac Pro is waiting to be sent away for repair. However, if this is a software bug, I'll see if I can get upgraded to 10.12.2 to see if the problem goes away!

Really pleased I saw this thread!

Downgraded my affected tester from 10.12.2 to 10.12.1 (16B2659 build) over the weekend, and I was no longer able to get this crash to happen on that build.

If anyone is seeing the WindowServer freezes in their organization after applying SecurityUpdate 2016-003 for El Capitan, and has AppleCare Enterprise, please open a ticket, referencing ticket number 100105893834, and let Apple know how many systems you have that are being affected by this issue. My guess is that Apple's Product Engineering is attempting to prioritize the fix based on affected systems.

Hi Robert

Did you download the update from https://support.apple.com/kb/DL1903?locale=en_US

I ask as the link wasn't available when it was first released and I had to download via swcdn link see

https://www.jamf.com/jamf-nation/discussions/22449/download-link-for-security-update-2016-003

The Apple kb has the update containing the 3 packages and the pkg is 486MB compared to the 331MB for the single pkg from swcdn.

I deployed the single package and I have the issues so I am now testing the bundled pkg to see if resolves the issue.

+1 on this.

I deployed the 3 pkg version the week after Christmas. I have not seen the formentioned issue. I'm in .edu, so our machines are caffeinated at boot and shutdown nightly. The release difference as @willjac037 mentioned, seems to be a firmware update pkg.

Larry

I've seen this happen also on a machine with the 2016-003 Security update that pretty much only runs iTunes 24x7. I was curious if the iTunes 12.5.4 update had any role in the problem too?

I noticed this post on Apple Discussions regarding Incompatible Kernel Extension Configuration Data published on 01/04. I realized that our test machines, which aren't seeing the freezing problem anymore, received this update, while production machines haven't yet. I've rolled this out to all, and I'm hopeful it will take care of the problem.

After installing El Capitan on my iMac, I also got the trouble you describe, several times each day, it was really frustrating. After posting on a norwegian forum, I got this answer:
https://support.apple.com/en-gb/HT201295
Resetting the SMC. And for two days I have not had any problem. Hope it will last forever!

The issue may be also triggered by installed virtualization apps (Fusion, VirtualBox).
in my case, I noticed powerd using up most of my late 2012 macmini cpu time.
I was able to kill it from terminal and my macmini was restored to normal operations

sudo killall powerd

The process gets respawned after a few seconds, so no need to take further actions.
It may be a workaround not to reboot every time the sluggishness comes up.
ciao

1) has nothing to do with the subsequent updates (Incompatible Kernel Extension Configuration Data)
2) has nothing to do with virtualization software
3) updates to our systems were applied via softwareupdate command from Apple's servers. I picked the 10 systems experiencing the issue the most and re-deployed the downloaded SecurityUpdate2016-003.pkg (from support.apple.com) to them
4) for most users the problem doesn't re-occur for 4-6 days, but for some users (have seen both Photoshop as well as Safari being triggers) it can take as little as an hour or two before the problem returns.

The posts from "hughmcintyre" in this thread on Apple Discussions (mentioned above) were most interesting. It does seem that some Sierra functionality was backported to 10.11.6, but not adequately tested...

Really really really hope Apple decides that this issue is worth fixing. We're going to Sierra in Feb/Mar (after 10.12.3 is out), but can't any sooner (in the middle of testing all of the ssh/logging/NFS changes in Sierra).

Has anyone noticed if this issue happens in Sierra? I have a few 10.11.6 machines exhibiting the freeze and all but 1 (a file server) use domain accounts. So the only machine I have available to test Sierra is a small file server due to the account locking bugs in 10.12. Not sure I want to sacrifice a server and have to rebuild it if Sierra does not resolve the freeze.

@RobertHammen

Did the re-deploying in your third bullet point resolve for you, or is it just listed there as something you've tried without resolving?

I've seen this on 10.12.2 with certain hardware- i.e. 15" touchbar had the issue, 12" MacBook did not. Have been unable to reproduce at all on any hardware with 10.12.1.

@tuinte Have tried it, but not enough data to determine if it did anything. Off to go look at firmware versions now...

@RobertHammen
Thanks for your diligence on this. Although we were not affected, I have disable the update from going out

I'm sure glad I finally stumbled across information on this problem! I have an iMac and a MacBook Pro (early 2011), both running El Capitan 10.11.6 and Security Update 2016-003, which was applied on December 20, 2016. Since that time, I've been experiencing what appeared to be "random" freeze-up's in the GUI - mouse would move, but mouse and keyboard input appeared to be ignored, and eventually things would finally unfreeze for a few seconds, then hang up again. The only "cure" was to forcibly reboot the afflicted machine, and resume working in fear that the problem would occur again within a few days. As I've experienced it, the problem is exactly as described by others in this forum thread.

Let's hope that Apple fixes this, and soon! Unfortunately, Apple doesn't have a great track record for acknowledging problems, and is often slow to provide fixes (and in some cases, never seems to get around to fixing certain problems). In the meantime, I guess our only recourse is to forcibly reboot the machine when this glitch rears its ugly head.

Looks like Apple just posted a Supplemental Update to Security Update 2016-003 for El Capitan (per @timsutton):

Only available via App Store/softwareupdate right now...

• Security Update 2016-003 Supplemental Update-10.11.6
  Security Update 2016-003 Supplemental Update (10.11.6), 364830K [recommended] [restart]

"The OS X El Capitan Security Update 2016-003 Supplemental Update fixes a kernel issue that may cause your Mac to occasionally become unresponsive."
